GRAIL 10-Helips-X
Measurement noise is than ±50fA of the industry's highest level
Specification(Cryogen transfer prober station)
| Item | GRAIL 10-Helips-X |
| Equipment configuration | Cryogenic prober main unit X 1set |
| Prove body outline dimensions | 915(w)×798(D)×600(H) |
| Weight | Prober main unit:150kg around |
| Cooling method | Refrigerant transportation Refrigerator Model Number:LT-3B |
| Measured temperature range | Lhe:< 6K～373K LN2:< 80K～373K |
| Area can be measured | < 25mm×25mm |
| Cooling time until the minimum temperature | < 60 minutes |
| Temperature Stability *1 | 6K～RT：±0.2K RT～373K：±0.5K |
| Measurement noise | < ± 50fA |
| Probe head | 0~6 pieces *1 |
| Probe mobility | X-axis:50mmFS Y/Z-axis:25mmFS |
| Signal connector | TRIAX connectorX(quantity probe+1) *2 |
| Sample Stage mobility | No transferring machanism |
| Options that can be mounted etc... *2 | Magnet kit / High temperature kit(200℃)/ Light introduction kit High withstand pressure kit / High frequency kit / Stage movement kit |
*1)I represents the number of portions of the "X"
*2)+1 is for the back gate
